- PRODUCT DETAILS
GREAT JUST GOT EVEN BETTER
The Fuse 3 is a tandem paraglider for professionals who demand maximum efficiency, reliability, and also flying pleasure.
The Fuse 2 was our most successful tandem ever, and the Fuse 3 builds on this platform. Notable improvements are an enhanced big ears control system and even more durable fabric yet in a lighter package:
- innovative big ears system makes it much easier to hold and release or even control with brakes
- exclusive, silicon-coated, durable-yet-lightweight fabric developed by GIN and Myungjin
- easy inflation and smoother take-off
- minimal shooting in strong conditions
- precise and well coordinated turn with super-light brake pressure
- first-class “thermal sniffing” ability
- great energy retention with trim off, or super-soft, progressive braking with trim neutral
- improved real-world performance in weak and strong conditions alike
- more durable yet lighter canopy fabric
- “Trim neutral” position indicator on risers
- replaceable trimmer webbing
As with the Fuse 2, the trim settings and wide weight range offer versatility for light pilots and passengers. The wing can also be flown solo.
Test pilot Tim Bollinger explains the philosophy behind the Fuse3:
“The Fuse 2 was our most successful tandem ever and has gained a big fan base in the professional tandem business all over the world, thanks to it being both easy to use and a pleasure to fly. That made it really challenging for us to improve this glider even more, especially as everyone was totally happy with the predecessor. But after one year of development and extensive testing in Korea, France and Switzerland we were finally happy with the new Fuse 3.
The Fuse series has always been known for its excellent take-off abilities in all conditions, its good performance and precise, playful handling. It was important to keep these qualities whilst introducing some new developments.
On the Fuse 3, we introduce a brand new fabric developed by GIN with Myungjin. It offers an extraordinary weight-to-durability ratio and is the result of over two years of testing and development all over the world in different conditions. Its coating is a PU- based composite, which makes it extremely durable, despite being lighter than the fabric we were using on the Fuse 2.
Although Myungjin is new to paragliding, they have many years’ experience in airsports fabrics for rescue parachutes. As a Korean company, close collaboration with Gin Gliders was a natural move. Myunjin have long been developing a new PU-based composite coating. After years of successful laboratory tests and extensive testing of the new fabric on various prototypes all over the world, we are happy. The Myungjin, MJ40MF (40 g) and MJ32MF (32 g) have shown excellent porosity and strength test results both in the laboratory, and also under real conditions.
We believe the fabric offers a real advantage on a glider like the Fuse 3, as tandem gliders are inherently exposed to abrasion and wear on take off, landing and repetitive packing.
With the new fabric being also lighter, the wing weighs in at 7.2kg, making the Fuse 3 one of the lightest everyday tandems on the market. This lightness makes the wing both compact on the ground and agile in the air.
We also worked a lot on the trimming of the brakes. Brake pressure has slightly decreased, and the handling is even more agile now. While you do not feel any difference in calm air, you have more control over the glider in rough air and you can turn tighter, making use of even small bubbles. The new brake setting helps also on the landing and increases the energy retention on the flair, which was already very good in the Fuse 2.
Based on the feedback from various professional tandem pilots in France we introduced a new big ear system on the risers. Now it is much easier and faster to pull and release the big ears. In addition to that, the pilot can still use the brakes and steer the glider. This especially helps on tricky top landings as the glide ratio can be easily adjusted.
We also took care to make the trimmers easy to change. Although we use the best available material on our trimmers, there is always some wear after extensive use. It is now possible to replace the trimmer webbing in just a few steps.
Overall we’re very happy with the Fuse 3 and hope tandem pilots will be too!”
- TECHNICAL DETAILS
- Optimized airfoil with Equalized Pressure Technology (EPT) for stability, handling and performance
- Exclusive new fabric developed by GIN and Myungjin offers outstanding durability with light weight
- Fully sheathed Edelrid lines for the best compromise of durability and performance
- Thin profile improves take-off and reduces material weight
- Line and riser layout optimized for big ears (large area of A3 and split A-riser)
- Clamp cleat system to lock big ears in place
- Long trimmers (11cm) enable greater penetration, for example in strong valley winds. The slightly negative and large positive trimmers allows you to adjust the speed over the whole weight range.
- Easy trimmer operation thanks to pulleys on the riser.
- Supplied with 20mm riser (706g). 12mm Kevlar risers (532g) are available as an option.
- Supplied with spreader bars (hard, 760g ea.). Supple (soft, 183g ea.) spreaders are available as an option.
- Supplied with XXL rucksack
- TECHNICAL SPECIFICATIONS
SIZE 37 41 Flat area (m2) 37 41.15 Flat span (m) 14.07 14.84 Flat aspect ratio 5.35 5.35 Projected area (m2) 31.34 34.86 Projected span (m) 11.08 11.69 Projected aspect ratio 3.92 3.92 Chord (m) 3.23 3.41 Number of cells 49 49 Glider weight (kg) 6.5 7.2 Weight range (kg) 90-190 90-220 Certification EN B EN B
Upper surface leading edge: Myungjin, MJ40MF 40g
Upper surface: Myungjin, MJ32MF 32g
Lower surface: Myungjin, MJ32MF 32g
